    Titanium Alloy Optical Dissolved Oxygen Monitor Sensor For Seawater Farms

    Ask Lasest Price
    Brand Name : Desun Uniwill
    Model Number : DS-380
    Certification : CE
    Price : $280.00 - $400.00/ Piece
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 1000 sets per month
    Delivery Time : 7~ 15 working days
    • Product Details
    • Company Profile

    Titanium Alloy Optical Dissolved Oxygen Monitor Sensor For Seawater Farms

    Optical Titanium Alloy Dissolved Oxygen Monitor Dissolved Oxygen Sensor For Seawater Farms


    Dissolved oxygen sensors and meters are commonly used in various industries to measure the amount of oxygen present in a liquid, typically in water. Optical sensors are commonly used in aquaculture to measure DO. They are based on the principle of fluorescence, where the sensor contains a dye that fluoresces in response to oxygen. The intensity of the fluorescence is directly proportional to the concentration of dissolved oxygen. Optical sensors are very accurate, and they respond quickly to changes in DO levels. They are also very stable and require very little maintenance. However, they can be expensive compared to other types of sensors.


    Desun-Uniwill-water-quality-sensors

    Dissolved Oxygen Sensor Brief Introduction

    The DS380 series of fluorescent dissolved oxygen sensors use a new type of fluorescence lifetime technology and high-performance fluorescent materials. The fluorescent dissolved oxygen sensor is based on the quenching principle of the specific fluorescence of a specific substance in physics. Blue light from a light-emitting diode (LED) illuminates the fluorescent material on the inner surface of the fluorescent cap, and the fluorescent material on the inner surface is excited to emit red light by detecting the phase difference between red and blue light and the internal calibration value. The ratio is calculated to calculate the concentration of oxygen molecules, and the final value is automatically compensated by temperature and pressure.

    Features of Fish Tank Dissolved Oxygen Sensor:

    -0-20mg/L or 0-200% saturation
    -0~50 °C; IP68 protection level
    -No film, no electrolyte, no polarization
    -No need to consume oxygen, no flow rate
    -Built-in temperature sensor, automatic temperature compensation
    -Free from chemical interferences such as sulfides
    -Small annual drift, fast response, and more accurate measurement
    -Free of maintenance, longer application cycle, and lower cost of use
    -Fluor cap replacement is simple
    -Support RS-485, MODBUS protocol

    Technical Specifications of Fish Tank Dissolved Oxygen Sensor:


    ItemParameters
    ModelDS380
    PrincipleFluorescence analysis method
    Measuring range0~20mg/L or 0-200% saturation
    Response time3 sec
    Accuracy1%
    Protection levelIP68
    InstallationSubmersible
    Temperature sensorNTC
    Temperature range0~50°C
    Temperature accuracy±0.2°C
    OutputSupport RS-485, MODBUS protocol
    Power supplyDC 6~12V, current <50mA
    SizeΦ26*155 mm
    Probe cable lengthDefault 5 m, customized 10m, 15 m and 30 m cable
    Fluorescent cap life1 year
    Maximum working pressure3bar
    Housing materialSS316/Titanium alloy





















    fluorescent DO sensors in aquaculture-Desun Uniwill
