Online COD BOD Sensor Waste Water Treatment RS485 Chemical Oxygen
Demand COD BOD Tester
Online COD BOD TSS analyzers are devices used to monitor and
measure the levels of organic matter and suspended solids in
wastewater. COD stands for Chemical Oxygen Demand, BOD stands for
Biological Oxygen Demand, and TSS stands for Total Suspended
Solids. These three parameters are important indicators of the
quality of wastewater and are used to ensure that the water is safe
to discharge into the environment.
The optical method online COD sensor (Chemical oxygen demand sensor) is more economical and environmentally friendly than the
traditional chemical method. Small in size, easy to install, and
can be used for continuous online water quality monitoring.
Automatic compensation for turbidity disturbances, with automatic
cleaning device, optional titanium alloy (corrosion resistant).
COD sensors are mainly used for monitoring rivers, lakes, sewage, and other
types of surface water, etc., and can be easily integrated into
water quality monitoring systems to meet customer needs.
* Digital sensor, RS-485 output, support MODBUS
* No reagents, no pollution, more economical and environmentally
friendly
* Can measure SAC, COD, TOC, and other parameters
* Automatic compensation for turbidity interference for excellent
test performance
| Product name | COD sensor |
|---|
| Detection principle | UV245nm UV Optics |
Measurement range
DS500
(6 mm gap) | COD 0 ~ 500 mg/lL
TSS 0~600 mg/L
BOD 0~300 mg / L |
Measurement range
DS500
(6 mm gap) | COD 0 ~ 2000 mg/lL
TSS 0~1000 mg/L
BOD 0~1000 mg / L |
Measurement range
DS501
(1 mm gap) | COD 6000~10000 mg/lL
TSS 0~5000 mg/L
BOD 0~5000 mg / L |
| Measurement accuracy | ±5% |
| Resolution | 0.01mg/L |
| Optical path | 1mm,6mm,10mm |
| Temperature range | 0~45℃ |
| Stored temperature | -40~80℃ |
| Output signal | RS-485, MODBUS protocol |
| Calibration method | 1 or 2 points |
| Automatic cleaning | Built-in cleaning brush |
| Waterproof level | IP68 |
|---|
| Under pressure | 1bar |
| Product material | 316/POM/Titanium alloy |
| Product Size | ∅46×218mm |
| Power information | DC 6~12V,Current <10mA |
| Cable length | Standard 5 meters |
Desun Uniwill Water quality sensors are designed to provide
accurate and reliable measurements of water quality parameters,
allowing for effective monitoring and management of water
resources. They are commonly used in various industries and
applications, including environmental monitoring, water treatment
plants, aquaculture, industrial processes, and research
laboratories.
Our Service
* Standardized workshop and process
* Strict professional quality inspection
* Return is supported if the product is unqualified.
* Fast delivery
* Warranty for 1 year
